XM-104 105mm Self-Propelled Gun
Photographed By James Hulse, September 9, 2021
1. XM-104 105mm Self-Propelled Gun Marker
Inscription.
XM-104 105mm Self-Propelled Gun. . In 1955 the U.S. Army established a requirement for a direct support, self-propelled artillery piece that would combine the best features of a light howitzer and a heavy mortar. This new light self-propelled howitzer would also be small and light enough to be air dropped, assault landed in the first phase of airborne operations or carried by helicopter. Using the same Ford engine as the M151 Jeep, it was capable of climbing a 60 percent grade and crossing a ditch 36 inches wide. The XM-104 was developed concurrently with the XM-102 light towed howitzer, which is on exhibit inside the museum. While the XM-102 was placed in production as the M-102 and used during the Vietnam War, the self-propelled XM-104 remained only a prototype. Built in 1963, it was used for experimental and test purposes by the Field Artillery Board until late 1970, when it was transferred to the museum., Caliber - 4.13 in. - 105 mm , Weight - 8,600 lb. - 3,901 kg , Range - 15,310 yd. - 14,000 m , Shell Weight - 33 lb. - 15 kg , Muzzle Velocity - 2,323 ft/sec. - 708 m/sec. , Elevation - (0 to + 75 degrees) - (0 to +1,333 mils) , Traverse - 45 degrees - 800 mils , Rate of Fire - 8-10 rpm - Crew 4 , Maximum Speed - 35 mph - 56 kph , Cruising Range - 300 miles - 483 km , Engine - Ford M151 4 cylinder, in-line, 66 hp , CCN# 108134
In 1955 the U.S. Army established a requirement for a direct support, self-propelled artillery piece that would combine the best features of a light howitzer and a heavy mortar. This new light self-propelled howitzer would also be small and light enough to be air dropped, assault landed in the first phase of airborne operations or carried by helicopter. Using the same Ford engine as the M151 Jeep, it was capable of climbing a 60 percent grade and crossing a ditch 36 inches wide. The XM-104 was developed concurrently with the XM-102 light towed howitzer, which is on exhibit inside the museum. While the XM-102 was placed in production as the M-102 and used during the Vietnam War, the self-propelled XM-104 remained only a prototype. Built in 1963, it was used for experimental and test purposes by the Field Artillery Board until late 1970, when it was transferred to the museum.
Caliber - 4.13 in. - 105 mm
Weight - 8,600 lb. - 3,901 kg
Range - 15,310 yd. - 14,000 m
Shell Weight - 33 lb. - 15 kg
Muzzle Velocity - 2,323 ft/sec. - 708 m/sec.
Elevation - (0 to + 75 degrees) - (0 to +1,333 mils)
Traverse - 45 degrees - 800 mils
Rate of Fire - 8-10 rpm - Crew 4
Maximum Speed - 35 mph - 56 kph
Cruising Range - 300 miles - 483 km
Engine - Ford M151 4 cylinder, in-line, 66 hp
CCN# 108134
Click or scan to see this page online
Erected by U.S. Army Field Artillery Museum. (Marker Number 490.)
Topics. This historical marker is listed in this topic list: War, Vietnam. A significant historical year for this entry is 1955.
Location. 34° 40.008′ N, 98° 23.16′ W. Marker is in Fort Sill, Oklahoma, in Comanche County. Marker is at the intersection of Corral Road and Randolph Road, on the right when traveling west on Corral Road. The marker is located in the central section of Artillery Park at the U.S. Army Field Artillery Museum. Touch for map. Marker is in this post office area: Fort Sill OK 73503, United States of America. Touch for directions.
2. The front side view of the XM-104 105mm Self-Propelled Gun and Marker
Marker and Museum are located on Fort Sill, an active U.S. military installation. The museum is open to the public, but appropriate identification is required for access for Fort Sill.
Also see . . . U.S. Army Artillery Museum. (Submitted on February 18, 2023, by James Hulse of Medina, Texas.)
Photographed By James Hulse, September 9, 2021
3. The serial number of the XM-104 105mm Self-Propelled Gun
Photographed By James Hulse, September 9, 2021
4. The back side of the XM-104 105mm Self-Propelled Gun
