U.S.S. Cairo Engine and Boilers

National Historic Mechanical Engineering Landmark

— 1862 —

U.S.S. Cairo Engine and Boilers Marker image. Click for full size.

Photographed by Mark Hilton, October 25, 2017

1. U.S.S. Cairo Engine and Boilers Marker

Inscription. The Cairo is the sole survivor of the fleet of river gunboats built by the Union during the Civil War with the object of controlling the lower Mississippi River. Designed by Samuel Pook and built by James B. Eads, the 175-foot ironclad vessel had 13 guns.

The propulsion system is the only known early example of the widely used "Western Rivers" steamboat engine, characterized by multiple fire-tube boilers with shared steam and mud drums and a two-cylinder noncondensing engine having a small bore, long stroke, and poppet valves. This engine was designed by A.T. Merritt. With a 22-inch bore and 6-foot stroke, it developed about 800 horsepower and drove a sheltered paddlewheel of 22-foot diameter and 15-foor width.

Erected 1990 by the American Society of Mechanical Engineers.

Topics and series. This historical marker is listed in these topic lists: Landmarks • Waterways & Vessels. In addition, it is included in the ASME Historic Mechanical Engineering Landmarks series list.

Location. 32° 22.551′ N, 90° 51.993′ W. Marker is in Vicksburg National Military Park, Mississippi,
